一、 Model and Main Parameters

1. Model: GFS/GT-10KW-D

2. Main parameters: The angle of attack can be manually adjusted (with four gears for installation in all seasons). The total power of the tree shaped photovoltaic power station is 10.72 kilowatts. Generate 10.72 ° C of electricity per hour and generate over 65 ° C of electricity per day (based on an average annual sunshine duration of 6-8 hours); Actual occupied area: 0.7 * 0.7=0.5 ㎡, actual coverage area: 9.5 * 5.5=52.5 ㎡; Minimum ground clearance height>2.3 meters (minimum ground clearance height can be adjusted according to customer needs)

二、 Main innovation points:

1. Innovation supported by photovoltaic modules: It subverts the traditional distributed photovoltaic power plant flat model, draws on the concept of tree growth upwards, and uses tree branches to support photovoltaic modules layer by layer upwards, greatly improving the installed capacity of the same area.

2. Innovation in bracket production: By using sheet metal parts with multiple node sets instead of welding processes, the production is more streamlined and the cost is significantly reduced. This eliminates welding deformation and damage to the surface coating, eliminating the need for secondary surface coating treatment. This greatly reduces the production cost.

3. Innovative installation method: Two 2 * 4 square arrays are symmetrically arranged on both sides, which can be installed flat and lifted with two support rods. Easy and fast installation.

4. Transportation innovation: The use of large tubes with small tubes inside greatly saves space.

三、 Patent certificate

四、 Application scenarios
