1、 Model and main parameters of vertical axis low-speed wind solar integrated power station

1. Model: JBLD/60Z-XX (Wind+Light) KW-5S.

2. Composition: Basic fixed base, tower components (three pipes standing in parallel, two sections), lower decorative cover, two panel photovoltaic modules (3 sets), low-speed (60r/min) power generation system, fan blade components (5 pieces), and control cabinet (can be customized according to customer requirements when off grid).

3. Main parameters: rated speed: 60r/min, rated voltage: 400V, 40HZ, rated wind speed: 13.8m/s, safe wind speed: 25m/s.

2、 Innovation points of vertical axis low-speed wind solar integrated power station

1. Convert high-speed permanent magnet generators into low-speed power generation systems to achieve wind power generation. Solved the global problem of wind not generating electricity. Realize 10-35% power generation from level 3 wind start-up, over 60% power generation from level 4 wind, full power generation from level 5 wind, and 100-140% power generation from level 6 to 9 wind.

2. The tower adopts three pipes standing in parallel, which increases the height adjustability of the tower, enhances wind resistance, facilitates transportation, and makes installation convenient and fast.

3. We have developed a quick assembly clamp, which securely binds the three pipes together, greatly enhancing the load and wind resistance torque of the tower.

4. The fan blade handle adopts a new material: basalt, which greatly reduces the weight of the fan blade handle and enhances its bending and torsional resistance.

3、 Vertical axis low-speed wind solar integrated power station patent
