It can be customized according to the requirements of the workpiece.

Sawing Machine -Vertical & Bevel Angle Example Parameter:

（1）Sawing cutting of various bars and thick wall pipes

（2）Adopt saw blade: TCL circular saw blade

（3）Saw blade diameter: TCL circular saw blade φ 460x2.25x60 teeth

（4）Saw blade speed: 80-120 rpm

（5）Saw feed drive: servo motor + ball screw

（6）Sawing area：○φ70—φ150  □70—100 mm  70—100mm

（7） Perpendicularity of saw cutting face to axis: ≤ 0.25/50mm (technical requirements for testing blank: φ 60 ± 0.05mm, surface roughness 3.2, straightness 0.25 / 500mm)

（8）Edge thickness uniformity tolerance: φ 60 length is 30mm ± 0.06mm

（9）Cutting length: single feeding maximum: 700mm, can be divided into multiple feeding, tail length 110mm.

（10）Hydraulic system pressure：6.3mpa

（11）Feeding drive: servo motor, ball screw

（12）Cooling mode: oil mist cold.

（13）Sawing efficiency: take 45 × steel φ 60mm as an example, 6-8 / blade per minute, and the sawing time of single blade of 150 round steel is about 90s.

（14）Tolerance of workpiece length after sawing: every 30mm ± 0.06mm.

（15）Sawable area of each saw blade: not less than 40m2 (take 45 × steel φ      60mm as an example, 16000-18000 knives can be cut)

（16）Barometric pressure：0.5-0.7mpa，4-8kg/cm²

（17）Voltage: three phase380V（±10%），50Hz

（18）Working environment requirements：0-40℃

（19）Total power of machine tool：24KW

（20）Boundary dimension of machine tool：2400*1800*2100mm

（21）Overall dimension of material rack：5000*1550*1200mm

（22）Attached is the quantity table of products that can be processed by each saw blade of the machine tool
