Plasma Cutting Machine - for Sheet



new energy


The CNC plasma cutting machine can cut any plane shape of straight line and arc.
◆The dynamic can be programmed directly on the machine, or drawn on the computer through the attached software, and copied to the operating system through the U disk to realize automatic cutting.
◆The equipment is widely used in automobile manufacturing, shipbuilding, fan manufacturing, kitchenware cabinet, ventilation and refrigeration, chassis cabinet, pressure vessel, steel structure processing, steel plate cutting, advertising cutting, sheet metal processing, engineering machinery, agricultural machinery and other machinery, boiler manufacturing, petrochemical equipment, light industry machinery, aerospace, decoration, large label manufacturing and other manufacturing industries

MESSAGE

You May Be Interested





BEST SELLERS





It can be customized according to the requirements of the workpiece.

Plasma Cutting Machine - for Sheet Example Parameter :

	Effective cut width	3000mm
	Effective cut length	13000mm
	Idle speed	0-10000mm/min
	Plasma cutting material	Suitable for low carbon steel plate, copper plate, iron plate, aluminum plate, galvanized plate, titanium plate and other metal plate
	Plasma cutting thickness	0-20mm
	Flame cutting thickness	6-100mm
	Machine speed	0-15000mm/min
	Lifting distance of cutting torch	≥200mm
	Machine accuracy standard	accord with JB/T5102-1999
	Automatic lifting accuracy	±0.3mm
	Linear positioning accuracy	±1mm/10m
	Linear repetition accuracy	±0.5mm/10m
	Setting speed error	≤±5%
	Cut roughness	Ra≤12.5μm
	The levelness between the two guides	≤±0.5 mm/10m
	he degree of parallelism between two guides	≤±2 mm/track
	Edge length error (quadrilateral)	≤±0.5 mm
	Diagonal error	≤±0.5 mm
	Diagonal straightness	≤±0.3 mm
	Return deviation	≤±0.2 mm
	Intersection point deviation	≤±0.5 mm
	Straight line deviation	≤±0.2 mm
		Machine tool manufacturing standards: meet and exceed JB/ t542-1999 standards
		Plasmacutting quality and dimensional deviation: meet and exceed JB/ t10045.4-1999 standard

Work and environment requirements:

The environment temperature		-10℃～+40℃
Relative humidity		≤95%No condensation
The surrounding environment		Ventilation, no big impact
The power supply voltage		220V/3×380V±10V
Power frequency		50Hz
Input power (local part)		3-5KW
	Plasma cutting gas (to be determined before delivery)	Argon, hydrogen, nitrogen, oxygen, air, water vapour and some mixture of gases
Oxygen inlet pressure		0.8-1.0ＭPa
Gas inlet pressure		0.04～0.06ＭPa 0.08～0.1ＭPa
xygen purity		More than99.6%
