Size

ength * width * height,mm）13000mm*3600mm*4000mm

Control model

CNC control

Main configuration

1.Intelligent feed unit 2. Three dimensional four head plasma drilling unit 3. Intelligent CNC control system

Working power

About 30 kw

Working stroke

Workpiece length：1500-12000mm

Processing area

Take square pipe as an example: meet the requirements of square pipe 300x300 profile hole making processing

Cytting machine

120 model

Working voltage

  AC380V/50Hz

Position positioning

accuracy

≦±0.2mm

Artificial

one

Price efficiency

To Ø 18 mm hole wall thickness, 6 mm hole number for about 30 seconds/root 75 (not including the time of loading)

Effective cut length

13000mm

Idle speed

0-10000mm/min

Plasma cutting material

Suitable for low carbon steel plate, copper plate, iron plate, aluminum plate, galvanized plate, titanium plate and other metal plate

Plasma cutting thickness

0-20mm

Flame cutting thickness

6-100mm

Machine speed

0-15000mm/min

Lifting distance of cutting torch

≥200mm

Machine accuracy standard

                        accord with  JB/T5102-1999

Automatic lifting accuracy

±0.3mm

Linear positioning accuracy

±1mm/10m

Linear repetition accuracy

±0.5mm/10m

Setting speed error

≤±5%

Cut roughness

Ra≤12.5μm

The levelness between the two guides

≤±0.5 mm/10m

he degree of parallelism between two guides

≤±2 mm/track

Edge length error (quadrilateral)

≤±0.5 mm

Diagonal error

≤±0.5 mm

Diagonal straightness

≤±0.3 mm

Return  deviation

≤±0.2 mm

Intersection point deviation

≤±0.5 mm

Straight  line deviation

≤±0.2 mm

Machine tool manufacturing standards: meet and exceed JB/ t542-1999 standards

Plasmacutting quality and dimensional deviation: meet and exceed JB/ t10045.4-1999 standard
