Laser Cutting Machine- for Pipe & Profile



new energy


Laser pipe cutting machine is developed according to the needs of customers in the profile and pipe cutting market. It adopts the latest CNC laser pipe cutting system to realize the control of pipe support device and chuck. With high degree of automation, high efficiency and high-cost performance. It can be customized according to the required workpiece.
◆The machine can meet the cutting of round pipe, square pipe, rectangular pipe and oval pipe made of carbon steel, stainless steel and aluminum alloy.
◆ It can be used in sports equipment, petrochemical industry, agricultural machinery, furniture, construction, construction machinery, food, etc

MESSAGE

You May Be Interested





BEST SELLERS





Can Be Customized

Laser Cutting Machine for Pipe & Profile Example Parameter :

Model	JBLD-TP
Laser generator	Raycus laser
Power of Laser	1000W 2000W 3000W 4000W 5000W 6000W（optional）
Cutable material	Stainless steel, carbon steel and other metal round pipes, square pipes, rectangular pipes, angle iron, channel steel, I-beam and special-shaped pipes, etc.
Cut through thickness	Depending on the material and its thickness
Length of cutting pipe	3000mm, 6000mm and non-standard customization (Optional)
Cutting Size	Tubeφ15-220mm, square tube φ15X15-145X145mm and non-standard customization
X, Y axis positioning accuracy	±0.05mm（6000mm ±0.05mm）
X, Y axis repeat positioning accuracy	±0.03mm/1000mm
X, Y maximum positioning speed	140m/min
A1, A2 axis stroke	N×360°
A1, A2 axis positioning accuracy	±0.05º
Positioning accuracy of rotating U-axis	Arc minutes ≤ 5
Electricity demand	380V/50Hz/60Hz/60A
Overall dimensions	9000x1500mm (take 6000mm stroke as an example)
